Chapter

3

Channel
Configuration
Data and
Status

This chapter explains how the Weigh Scale module and the processor communicate
through the module's input and output image.


For CompactLogix / RSLogix5000 setup, please refer to Appendix A

With RS Logix500 software, verify the module ID code.

Expansion General Configuration

Weigh
Scale
Module ID
Code = 1

Vendor ID = 3

Product Type = 9

Product Code = 1

Series/Major Rev/Minor Rev = D

No special I/O configuration (SPIO CONFIG) information is required. The module ID code
automatically assigns the correct number of input and output words. The following memory map
shows how the output and input image tables are defined.

The 8 word output image (output from the CPU to the module) contains
Information that you configure to define the way a specific channel will work.

Output Image

Example – If you want to configure channel 2 on the module located in slot 4
in the SLC chassis, your address would be O:4.2.
(

o = file type : =element delimiter 4=slot .=word delimiter 2=word

)

Bit

Reserved

O:e.0/0

Bit

Reserved

O:e.0/1

Bit

Reserved

O:e.0/2

Bit

Zero Stabilize 0=Off 1=On

O:e.0/3

Bit

LSD Flicker 0=Off 1=On

O:e.0/4

Bit

Vibration Filter 0=Off 1=On

O:e.0/5

Bit

Channel

2

Trim

O:e.0/6

Bit

Coarse

Zero

Up

Adjust

O:e.0/7

Bit

Channel

1

Trim

O:e.0/8

Bit

Reserved

O:e.0/9

Bit

Reserved

O:e.0/10

Bit

Reserved

O:e.0/11

Bit

Coarse Zero Down Adjust

O:e.0/12

Bit

Clear

Tare O:e.0/13

Bit

Tare

O:e.0/14

Bit

Channel Toggle 0=CH1 1=CH2

O:e.0/15

Integer

Channel 1 Scale value

O:e.1

Integer

Channel 1 mV/V Setting

O:e.2

Integer

Channel 1 A/D Trim Setting

O:e.3

Integer

Channel 2 mV/V Setting

O:e.4

Integer

Channel 2 A/D Trim Setting

O:e.5

Integer

A/D Samples Setting

O:e.6

Integer

Channel 2 Scale value

O:e.7

Page 3-1
