EH
9
2.4. Technical specifications
EH
Working temperature range °C 20 ... 150
Temperature stability °C ±0.03
Temperature selection digital
Temperature indication LED
Resolution °C 0.1
ATC - Absolute Temperature Calibration 1-point
Temperature control PID1
Heater wattage (at 230 V) kW 2.0
Heater wattage (at 115 V) kW 1.0
Circulating pump:
discharge, max.at 0 bar l/min 15
pressure, max. at 0 l bar 0.35
Electrical connections:
External alarm device Vdc/mA 24-0 Vdc / max. 25mA
Overall dimensions (WxDxH) cm 13x15x33
Usable bath depth cm 8 ... 14.5
Weight kg 3,3
Ambient temperature °C 5 ... 40
Mains power connection 230 V/50 Hz V/ Hz 190-253 / 50
Current input (208V / 230 V) A 8 / 9
Mains power connection 230 V/60 Hz V/ Hz 190-253 / 60
Current input (208V / 230 V) A 8 / 9
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current input (at 115 V) A 9
Mains power connection 100 V/60 Hz V/ Hz 90 ... 110 / 60
Current input (at 100 V) A 9
All measurements have been carried out at:
rated voltage and frequency operating temperature: 70 °C
ambient temperature: 20 °C bath fluid: water
Technical changes without prior notification reserved.
