JULABO EH Heating Immersion Circulator - Manual (Page 15)

EH
15
5. Preparations
5.1. Installation
Caution:
Securely fix the immersion circulator. The heater may not be in contact with the
wall of the bath tank. Keep a distance of at least 15 mm.
Units not adequately fixed may drop into the bath tank.
D a n g e r o f e l e c t r i c s h o c k !
First pull out the power plug to disconnect the unit from the power supply net.
Then take the immersion circulator out of the bath tank.
Make a service technician check the instrument before it is used again.
 Place the unit on an even surface on a pad made of non-
flammable material.
 The heating immersion circulator is mounted using a bath
attachment clamp (21) designed for bath wall thicknesses
up to 26 mm.
21
22
 Use the two sleeves (22) supplied with the unit to reduce
the immersion depth from 165 mm to 145 mm (see
drawing).
 For use with glass vessels a stand attachment with rod is
available as optional accessory.
(order no. 8 970 022)
