JULABO ED Heating Immersion Circulator - Manual (Page 8)

Operator responsibility – Safety recommendations
8
2.4. Technical specifications
ED
Working temperature range °C 20 ... 100
Temperature stability °C ±0,03
Temperature selection digital
Temperature indication LED
Resolution °C 0.1
Temperature control PID1
Heater wattage (at 230 V) kW 2,0
Heater wattage (at 115V) kW 1,0
Circulating pump:
discharge, max.at 0 bar l/min 15
pressure, max. at 0 l bar 0.35
Overall dimensions (WxDxH) cm 13x15x33
Usable bath depth cm from 8 to 14.5
Bath opening (WxL) cm -----
Bath depth cm -----
Filling volume liters -----
Weight kg 3.3
Ambient temperature °C 5 ... 40
Mains power connection 230 V/50 Hz V/ Hz 190-253 / 50
Current input (at 230 V) A 9
Mains power connection 230 V/60 Hz V/ Hz 190-253 / 60
Current input (at 230 V) A 8 / 9
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current input (at 115 V) A 9
Mains power connection 100 V/50-60 Hz V/ Hz 90-110 / 50-60
Current input (at 100 V) A 9
All measurements have been carried out at:
rated voltage and frequency operating temperature: 70 °C
ambient temperature: 20 °C bath fluid: water
Technical changes without prior notification reserved.
