71
Enhanced Wireless Router
sections
table of contents 1 2 3 4 5 6 8 9 10 7
ManUally ConfIgURIng nETWoRK sETTIngs
Manually Configuring network settings in Mac os X
3� Select “Built-in Ethernet” (1) next to “Show” in the “Network”
menu�
4� Select the “TCP/IP” tab (2)� Next to “Configure:” (3), you should see
“Manually” or “Using DHCP”� If you do not, check the PPPoE tab
(4) to make sure that “Connect using PPPoE” is NOT selected� If it
is, you will need to configure your Router for a PPPoE connection
type using your user name and password�
1� Click on the “System
Preferences” icon�
2� Select “Network” from the “System Preferences” menu�
(1)
(3)
(4)
(2)
