background image

1. Applications

KOLVER electric screwdrivers are used to tighten to the required torque screws,
nuts, studs and any other kind of threaded connection on any material. Table 1 will
show you the capacity and the torque range of this screwdriver. Obviously, it is
possible to use the screwdrivers with screws having a larger diameter if the torque
falls within the indicated range. All models are reversible and can consequently be
used to unscrew. Electric screwdrivers are mainly used in the electronic and
mechanical industry as well as for electric appliances, wiring, lamps, etc.

Table

1

2. Use

The screwing system is composed by a screwdriver, a cable with 5 pin connectors
and by a control unit and power supply. To install it please follow the instructions.

a) Connect the 5-pin plug of the cable to the controller socket and to the
screwdriver and tighten the relevant nuts.
b) Push the collect ring of the quick charge chuck towards the body of the
screwdriver, insert the desired bit into the exagonal seat ¼’’ and release the ring.
c) Connect the controller plug to a mains supply socket 230V-50Hz.
d) Switch on the controller through the green light button “POWER”.
e) Position the bit head firmly into the fastener head, press the starting trigger and
run the faster down. The tool stops automatically when the preset torque is reached
and it is ready for the following operation.

WARNING: PLUTO series can reach torque values up to 15Nm. These
screwdrivers should be always clamped on a torque reaction arm such as
PA2KOL or DMFK90 to eliminate the reaction. Failure to do so may result in
operator injury and damage to the work piece.

IMPORTANT: For each second of operation the motor needs 3 seconds of
rest, as indicated on the tool label (1s/3s). Failure to do so may result in motor
overheating and eventually damage and will be considered as a misuse. Our
warranty will not apply.

Model

Capacity

MAX RPM

Torque range Nm

PLUTO 10

M5-M8

600

0,6 – 10,0

PLUTO 15

M5-M8

320

0,6 – 15,0

PLUTO 3

M5

1200

0,3 – 3,0
