2.3.5. 2.3.5. 2.3.5. 2.3.5. Capture Capture Capture Capture messages messages messages messages
Code ID 0xE0-0xE1
Description Get Capture Version
Payload None
Response “Capture Version String” or {0} if not applicable
Code ID 0xE2-0xE3
Description Get Mode
Payload None
Response 1 byte:
{0 = trigger, , 2 = disabled}
Code ID 0xE4-0xE5
Description Set Mode
Payload 1 byte OR
{0 = trigger, 2 = disabled}
Response 1 byte:
{(Bit 0: Success)}
Code ID 0xE6-0xE7
Description Get Data Format
Payload None
Response 1 byte:
{(Bit 2:Timestamp)
(Bit 1: Capture Prefix)
(Bit 0: Capture Suffix)}
Code ID 0xE8-0xE9
Description Set Data Format
Payload 1 byte:
{(Bit 7 = 0: Timestamp config select, =1: Timestamp config deselect)
(Bit 6 = 0: Capture Prefix config select, =1: Capture Prefix config deselect)
(Bit 5 = 0: Capture Suffix config select, =1: Capture Suffix config deselect)
(Bit 2:Timestamp)
(Bit 1: Capture Prefix)
(Bit 0: Capture Suffix) }
Response 1 byte:
{(Bit 0:Success)}
Code ID 0xEA-0xEB
Description Get Capture Prefix
Payload None
Response 1-33 bytes:
{ Capture Prefix length}
