Buffalo Technology Buffalo AirStation MIMO WZR-G108 - Manual (Page 2)

Wireless LAN Interface
Standard Compliance IEEE 802.11b / IEEE 802.11g,
MIMO (Multi Input Multi Output)
Communication Protocol Direct Sequence Spread Spectrum (DSSS),
OFDM
Frequency Range 2.412 - 2.462 GHz
Transmission Rate MIMO: 72, 96, 108 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
Access Mode Infrastructure Mode
Antenna 2.4 GHz Antenna x 3 (external)
Security WPA-PSK (AES, TKIP), 128/64-bit WEP,
MAC Address Filter
Selectable Channels 11 Channels
Hardware
Interface
OS Support
IEEE 802.11b / IEEE 802.11g,
MIMO (Multi Input Multi Output)
Direct Sequence Spread Spectrum (DSSS),
OFDM
2.412 - 2.462 GHz
MIMO: 72, 96, 108 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
Infrastructure Mode
2.4 GHz Antenna x 3 (internal)
WPA-PSK (AES, TKIP), 128/64-bit WEP
11 Channels
Spectrum (DSSS), OFDM
32-Bit CardBus
Windows ® 2000, Windows ® XP
Wired LAN Interface (WZR-G108)
Standards Compliance IEEE802.3u (100 Base-TX),
IEEE802.3 (10 Base-T)
Transmission Rate 10/100 Mbps
Transmission Encoding 100 BASE-TX 4B5B/MLT-3,
Method 10 Base-T Manchester coding
Access Method CSMA/CD
Number of LAN Ports 4
WAN Port 10/100 Mbps, Auto Sensing, Auto MDIX,
High-Speed Routing to Support FTTH
Number of WAN Ports 1
WAN/LAN Port Connector RJ-45
Security Dynamic Packet Filtering, Intrusion Detector,
NAT/SPI Firewall
Others
Power Supply 100-240V AC Universal, 50/60 Hz
Power Consumption About 9.4 W
Dimensions 8.5 x 7.0 x 1.9 in. (215 x 177.6 x 47.5 mm)
Weight 1.2 lbs. (560 g)
Operating Environment 0-40°C, 20-80% (non-condensing)
Technical Specifications
AirStation MIMO Wireless Cable/DSL Router -WZR-G108
AirStation MIMO Wireless Notebook Adapter - WLI-CB-G108
4030 W. Braker Lane # 120
Austin, TX 78759
800-456-9799
www.buffalotech.com
Buffalo Technology (USA), Inc. is a
leading global provider of affordable,
easy-to-use, next-generation wired
and wireless network solutions for the
consumer, SOHO and SMB markets.
With its expansion into the U.S. retail
market, Buffalo offers home users a
full suite of wireless home networking
solutions such as its award-winning
line of AirStation 54g products; its
125* High-Speed Mode™ 802.11g
products; and its versatile line of
802.11a/b/g combo products. Buffalo
completes its offerings with additional
world-class networking solutions that
include memory, storage and
multimedia products – perfectly suited
for any wireless environment.
© Buffalo Technology (USA), Inc. Buffalo Technology, Buffalo Technology logo and AOSS logo are registered trademarks of Buffalo Technology
(USA), Inc. The names and logos of other companies mentioned herein belong to their respective owners.
WLI-CB-G108
WZR-G108
WZR-G108 WLI-CB-G108
2.1 x 0.4 x 4.8 in. (54 x 10 x 123 mm)
1.8 oz. (50 g)
0-55°C, 20-80% (non-condensing)
(products sold separately)
WZR-G108
Cable/DSL
Modem
Wireless
Notebook
with
Notebook
Adapter
(1)
(2)
• (1) Press the AOSS button on the router
to initiate the AOSS session.
• (2) Click on the AOSS icon in the
Buffalo Client Manager Software.
AOSS™ - One Click. One Touch. Done.
• Done - A secure connection is automatically
established between the Router and the Notebook. AOSS functions between Buffalo AOSS enabled devices only. Buffalo client devices are AOSS enabled by using Buffalo’s
updated client manager software (Windows clients only).
up to
8x
Speed! up to
8x
Speed!
up to
3x
Distance! up to
3x
Distance!
of standard 802.11g
