GH-505
Page 8
Button Description
ESC/LAP In Menu mode, press ESC button to escape from the current page and go back
to the previous page.
Press ESC button to split a lap when timer is running.
Power Press 2 seconds to turn on/off GH-505.
When GH-505 is on, quickly press this button will turn on/off the backlight.
Press and hold this button for 14 seconds to do hardware reset if the system is
halted.
PG (Page) Switch between the screens of “Menu mode”, “Location mode”, “Speedometer
mode” and “Map mode”.
Up / Down To move upward/downward for highlighting an item.
In Speedometer mode, press to switch between two views.
In Map mode, press to zoom in or zoom out.
OK / Enter Press to enter the highlighted item.
Press to confirm data entry or feature selection in Menu mode.
In Speedometer mode, press to start/stop the timer.
3.3 Antenna Introduction
The GPS antenna is located in the lower part of
the device. Let it face to the sky for a better
reception.
