2
TABLE OF CONTENTS BASIC DETAILS …………………………………………………………... Page 2
GENERAL ………………………………………………………………….. Page 2
MAJOR COMPONENTS …………………………………………………... Page 3
ACCESSORIES …………………………………………………………….. Page 3
USE …………………………………………………………………………. Page 3
HYDRAULIC REQUIREMENT …………………………………………... Page 3
INSTALLATION …………………………………………………………... Page 3
CONTROLS ………………………………………………………………... Page 4
WINCH CLUTCH AND DRAG BRAKE INFORMATION .……………... Page 4
CALIPER BRAKE ASSEMBLY INSTALLATION ………………………. Page 6
AUTOMATIC BRAKE …………………………………………………….. Page 6
PREPARING FOR OPERATION………………………………………….. Page 7
OPERATING THE WINCH ………………………………………..………. Page 7
MAINTENANCE …………………………………………………………... Page 8
LUBRICATION ………………………………………………..…………... Page 8
PRECAUTIONS ……………………………………………………………. Page 9
WIRE ROPE INFORMATION …………………………………………….. Page 10
WINCH IDENTIFICATION ……………………………………………….. Page 11
ACCESSORIES …………………………………………………………….. Page 11
BASIC DETAILS CD-22 CD-28
Maximum Rated Pull-Bare Drum 20,000 lbs. 20,000 lbs.
Maximum Rated Pull-Full Drum 9,000 lbs. 9,000 lbs.
Drum Width 22.5” 28”
Net Weight 925 lbs. 935 lbs.
Cube Dimension 24” High X 24” Wide X 60” long 65” long
GENERAL The Model CD-22 and CD-28 winches are derived from Bell System Spec. 8003-
LlB and 8003-L2B. Differing only in the drum width, they are suitable for appli-
cations involving stationary or mobile mounting. Driven by a series of highly
efficient helical gears, these units will not generate excessive heat under long,
maximum pull conditions.
