General Machine Products CD-28 Adams Manual User Manual
Page 12

12
Winch Input
Gear Ratio
Control Valve
Position
Winch Line Speed
(ft./min.)
30 GPM
Bare drum Full Drum Bare Drum Full Drum
19.9:1 High 10,000
4,500 82 177
19.9:1 Intermediate
16,100
7500
49
106
19.9:1 Low
12,000 27 58
Maximum Rated Line
Pull (lbs.)
Winch
Gear
Ratio
Maximum Rated
Line pull (Ibs.)
Winch Line Speed*
(Ft./min.)
Bare drum Full drum Bare drum Full drum
19.9:1 20,000 9,000
Input
RPM
9
Input RPM
4.1
SPECIFICATIONS
Line pull & line speed capacities
Hydraulic Tri-Drive Three-Speed
Transmission (Model 230-1600)
• Rated working capacity: 20,000 lbs. bare drum pull
• Winch input torque: 4,750 in./lbs. max. at 600 RPM
• Winch input speed: 1,600 RPM max.
• Rated working capacity: 20,000 lbs. bare drum pull
• Hydraulic flow: 30 GPM maximum
• Hydraulic system pressure: 2,000 psi operating
2,100 psi maximum bypass relief
If actual operating pressure exceeds recommended maximum, in low con-
trol valve position, the winch will generate a pulling force beyond its rated
working capacity. Such a condition can damage the winch, cause wire rope
failure or result in injury to persons or property. It is most important that the
maximum operating pressure be restricted to permit a specifically limited
winch line pull.
• IMPORTANT NOTE: Winch line speed based on 9/16"
dia. wire rope for all drive types.
1
1
• Rated working capacity: 20,000 Ibs. bare drum pull
• Hydraulic system flow: 55 GPM maximum
• Hydraulic system pressure: 2,000 psi operating 2,200 psi maximum bypass relief
Winch Input
Gear Ratio
Gear Position Maximum Rated Line Pull
(Ibs.)
Winch Line Speed* (ft./min.)
30 GPM
40 GPM
Bare drum
Full drum
Bare drum
Full drum
Bare drum
Full drum
Bare drum
Full dram
19.9:1
High
7,400
3,400 107 229 149 321 213 459
19.9:1
Intermediate
18,700
8,700
42 91 59 127 85 182
19.9:1 Low
20,000
18 39 25 54 36 77
55 GPM
Hydromechanical Three-Speed Transmission (Model 240-584)
2
In low gear, this winch can generate a pulling force beyond the maximum rated capacity of the winch and possibly the wire rope. Such a condi-
tion can damage the winch, cause wire rope failure or result in injury to persons or property. Use low gear with extreme caution for slow speed
operation only. It is most important that the maximum operating pressure be restricted to permit a specifically limited winch line pull.
2
Winch model 5/16"Dia.
3/8"Dia.
7/16"Dia. 1/2" Dia.
9/16" Dia.
CD-22 4,600
2,600
2,100
1,600
1,300
CD-28 5,800
3,600
2,700
2,000
1,700
Wire rope drum storage capacities (by rope size)
Winch
Model A B C D E
F
G
H
J K L
Wt.
(lbs.)
CD-22 22.5 11.25 8 19 46.5 36.37 26.37 14.37 25.75 4 24 925
CD-28 28
14 8 19 52 35.25 29.37 14.37 25.75 4 24 935
Basic winch dimensions (in inches)
General Machine Products Co., Inc.
3111 Old Lincoln Hwy.
Trevose, PA 19053
Tel: 215-357-5500
Fax: 215-357-6216
Email: [email protected]
GMP reserves the right, without
notice, to make changes in
equipment design or compo-
nents as progress in engineering
or manufacturing methods may
warrant.
• Wire rope lengths are based on the winch being equipped with a Model CH Level-Wind.
• Selection of the proper wire rope diameter, with a maximum breaking strength and allowable pull
appropriate for use on winches such as the CD-22 and CD-28, is the responsibility of the user.
