Bowers & Wilkins 7 NT - Manual (Page 23)

II08672
Issue
1
Signature ™ 7NT
Technical Features
Description
Drive units
Frequency response
Sensitivity
Nominal impedance
Crossover frequency
Recommended amplifier power
Frame size
Cut-out size without
pre mount frame
Cut-out size with
pre mount frame
Min depth required
Finishes
Pre-mount frame (optional)
Nautilus ™ Tweeter
Kevlar cone
2-way system
1x 180mm (7in) Kevlar ® mid/bass
1x 25mm (1in) metal dome high-frequency
40Hz – 25kHz ±3dB
88dB spl (2.83V, 1m)
8Ω
3.5kHz
20W–150W continuous into 8Ω
on unclipped programme.
Height: 371mm (14.6in)
Width: 255mm (10in)
Height: 337mm (13 .3in)
Width: 220mm (8.7in)
Height: 343mm (13.5in)
Width: 226mm (8.9in)
98mm (3.8in) From wall surface
Semi-matt white suitable for customising
or pre-painting
PMK ™ 800
Kevlar is a registered trademark of DuPont. E & OE.
B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments.
Copyright © B&W Loudspeakers Ltd. Printed in England.
B&W Loudspeakers Ltd, Meadow Road, Worthing, BN11 2RX Tel: +44 (0) 1903 524801 Fax: +44 (0) 1903 524725
B&W Loudspeakers of America, 54 Concord Street, North Reading, MA 01864-2699, USA
Tel: (1978) 664 2870 Fax: (1978) 664 4109
http://www.bwspeakers.com
