Function Test Garland RTCSmp Induction Built-in Griddles
Part # 4532291 Rev 2 (01/15/14) 17
5 Function Test
IMPORTANT
CAUTION
When the unit is in use, the griddle plate is hot. To avoid
burn injuries, do not touch the unit during operation.
• Before carrying out the function test, the user must understand how to operate the unit.
• Remove all objects from the griddle plate.
• Ensure the grease collector (custom-made) is installed properly before operating the unit.
To perform a function test:
1. Turn the control knob to set the temperature to 392°F (200°C).
2. The display shows the set temperature value.
3. If the set temperature (392°F / 200°C) is not changed, within 2 seconds, the display changes from the set
temperature (displaced with point ) to the actual temperature (displayed without point
).
4. The griddle plate warms up to the set temperature.
5. As soon as the plate temperature reaches the set temperature of 392°F (200°C), turn the control knob to
position 0 (OFF).
NOTE: The fan should start once the temperature reaches 392°F / 200°C.
6. If the sensors detect enough residual heat, the display shows “HOT”.
7. If the residual heat from the griddle plate is low, the control system of the induction unit initiates the
stand-by mode. When the system is in the stand-by mode, the point on the display blinks once every
second.
For assistance, see chapter 10 Troubleshooting or call a Factory Authorized Service agency.
