GAM 4 & 6 GOBO TRAY TS6140 - Manual (Page 3)

Page 3 of 4 www.rosco.com
DMX Level
255
129
128
127
0
Channel Level
100%
51%
50%
49%
0%
Direction
Fast counterclockwise
Variable speed levels
Slow counterclockwise
STOPPED
Slow clockwise
Variable speed levels
Fast clockwise
MODE 5 OPERATION • MODE SWITCH = 5
Standalone operation for continuous rotation
• X100 sets the direction - Select 1 for counter-
clockwise rotation or 2 for clockwise rotation
• X10, X1 sets speed of rotation - 00 is the slowest
and 63 is the fastest speed
MODE 6 OPERATION • MODE SWITCH = 6
Rotation DMX controlled only
• Applies to single pattern disc effects.
• Select DMX control channel on SX4® switches
X100, X10 and X1
• Selected channel fader operates speed and
direction of rotation as per chart below
MODE 8 OPERATION • MODE SWITCH = 8
DMX two channel indexing with variable
speed rotation
• Applies to single pattern disc effects and gobos
• Select DMX control channel on SX4® switches
X100, X10 and X1
Control channel fader has two functions:
• Operates as an indexing fader from zero to 99%
• If set at 100%, then it holds the disc in
continuous rotation mode
DMX Level
255
130
129
128
0
Channel Level
100%
52%
51%
50%
0%
Direction
Slow clockwise
Variable speed levels
Continuous rotation
Fast clockwise
STOPPED
360 degrees
Indexing to position
with shortest route
maximum speed
0 degrees (home)
MODE 7 OPERATION • MODE SWITCH = 7
DMX single channel linear indexing and
rotation control
• Applies to single pattern disc effects
• Select DMX control channel on SX4® switches
X100, X10 and X1
• Control channel fader operates index/rotate
functions as per chart below
SETTING UP CHOICES FOR CHANNEL 1
DMX Level
255
254
0
Channel Level
100%
99%
0%
Direction
Continuous rotation mode
359 degrees
Variable index positions
0 degrees (home)
Second channel controls speed & direction of disc
when 1st channel is set at 100% continuous
rotation mode.
Direction
Fast counterclockwise
Variable speed levels
Continuous rotation
Slow counterclockwise
STOPPED
Slow clockwise
Variable speed levels
Continuous rotation
Fast clockwise
DMX Level
255
129
127, 128
126
0
Channel Level
100%
51%
50%
49%
0%
Direction
Fast counterclockwise
Variable speed levels
indexing
Slow counterclockwise
Slow clockwise
Variable speed levels
Continuous rotation
Fast clockwise
Shortest route full speed
DMX Level
255
128
127
1
0
Channel Level
100%
51%
50%
1%
0%
SECOND CHANNEL CONTROLS SPEED & DIRECTION OF DISC
PER CHART WHEN 1ST CHANNEL IS SET FROM 0-9
INDEXING MODE
SECOND CHANNEL CONTROLS SPEED & DIRECTION OF DISC
PER CHART WHEN FIRST CHANNEL IS AT 100% CONTINOUS
ROTATION MODE
