GAM DISC TRAY TS6130 - Manual (Page 2)

Page 2 of 2 www.rosco.com
MODE 8 OPERATION • MODE SWITCH = 8
DMX two channel indexing with variable
speed rotation
Select DMX control channel on SX4® switches
X100, X10 and X1
Control channel fader has two functions:
• Operates as an indexing fader from zero to 99%
• If set at 100%, then it holds the disc in
continuous rotation mode
SETTING UP CHOICES FOR CHANNEL 1
DMX Level
255
254
0
Channel Level
100%
99%
0%
Direction
Continuous rotation
359 degrees
Variable index positions
0 degrees (home)
Second channel controls speed & direction of disc
when 1st channel is set at 100% continuous
rotation mode.
Second channel controls speed & direction of disc
when 1st channel is set from 0-9 indexing mode.
SETTING UP CHOICES FOR CHANNEL 2
Direction
Fast counterclockwise
Variable speed levels
Continuous rotation
Slow clockwise
STOPPED
Slow clockwise
Variable speed levels
Continuous rotation
Fast clockwise
DMX Level
255
130
129
128
0
Channel Level
100%
52%
51%
50%
0%
SETTING UP CHOICES FOR CHANNEL 2
Direction
Fast counterclockwise
Variable speed levels
indexing
Slow counterclockwise
Slow clockwise
Variable speed levels
Continuous rotation
Fast clockwise
Shortest route full speed
DMX Level
255
128
127
1
0
Channel Level
100%
51%
50%
1%
0%
100%
0%
100% = 359
Indexing
0 Degree
Channel 1
COARSE POSITION
MODE 9 OPERATION • MODE SWITCH = 9
DMX two channel highly accurate 16 bit linear
indexing for all disc types
Select DMX control channel on SX4® switches
X100, X10 and X1
Use channel 1 for the whole degree positions and
channel 2 for fine alignment positions between the
single degree settings of channel 1.
100%
0%
100% = 1º
Fine
Indexing
0 Degree
Channel 1
FINE POSITION
