BT Relate 2100 User Manual
Page 7
2. Connect the telephone line cord and mains power cables
to the underside of phone.
3. Route the cables as shown below for wall mounting or
desk mounting.
7
Getting started
The base station must be plugged
into the mains at all times.
Use the channels going up for
desk mounting.
Use the channels going down for
wall mounting.
BT Relate 2100 (BT SMS Server) – Edition 5 – 23.04.04 – 5799
TB –
B –
Route for wall mounting
Route for desk mounting
Handset
cord
Telephone
line cord
Mains
power
cable
