2
section
Introduction
1
2
3
4
3 2
Power LED
Solid Green – Connected to powerline
Off – Power off
Blinking Green – During encryption setup
Solid Green – Encryption setup successful
Double Flash – Fail in encryption
Powerline Link LED
Blinking – Powerline data transmitting or receiving
Color Green – Link rate excellent: greater then 20Mbps
Color Yellow – Link rate normal: 10–20Mbps
Color Red – Link rate low: 0–10Mbps
Off – No activity
Ethernet Link LED
Solid Green – 10/100Mbps port linked
Blinking Green – 10/100Mbps port transmitting or receiving
Off – No Ethernet link
System Requirements
• At least 2 HomePlug devices
• Available Ethernet port on each computer or network device
• Available power outlet
• Standard home powerline wiring
• CD-ROM drive
Package Contents
• Two Powerline AV Networking Adapters
• HomePlug Quick Installation Guide
• HomePlug User Manual (on CD)
• CD-ROM
• Limited Warranty Card
• Two Power Cables
• Two CAT5/RJ45 Ethernet Cables
• Two Wall Plug Adapters
