PIC Starter Addendum

Elmo Motion Control

Rev. 8/99

PIC - STARTER

Addendum to the PIC Operating Manual

Revision 8/99

Introduction

This addendum is intended for the use of the design engineer who uses a PIC amplifier
with a PIC-STARTER evaluation and interface board. This document should be
regarded as an extension to the “PIC Operating Manual”, describing ONLY the pins
and functions (of the PIC amplifier) that are either different or slightly modified from
the description in the “PIC Operating Manual”. The chapters in this document are
sequenced in correlation to the chapters in the “PIC Operating Manual” that cover the
same information.
