2.4. How to Use this Guide
In order to install and operate the Trombone servo drive, you will use this manual in
conjunction with a set of Elmo documentation. Installation is your first step; after carefully
reading the safety instructions in the first chapter, the following chapters provide you with
installation instructions as follows:
•
Chapter 3 - Installation
, provides step-by-step instructions for unpacking, mounting,
connecting and powering up the Trombone.
•
Chapter 4 - Technical Specifications
, lists all the drive ratings and specifications.
When you have completed the instructions in this guide, the Trombone servo drive should be
successfully mounted and installed. From this stage, you need to consult higher level Elmo
documentation in order to set up and fine-tune the system for optimal operation:
•
The SimplIQ Software Manual, which describes the comprehensive software used with the
Trombone
•
The SimplIQ Command Reference Manual, which describes, in detail, each software
command used to manipulate the Trombone motion controller
•
The Composer Software Manual, which includes explanations of all the software tools that
are part of Elmo’s Composer software environment
