Broilmaster S5 SERIES GRILL - Manual (Page 17)

ITEM
NO. DESCRIPTION QTY. S5CP S5NWO
1 Lid Casting Ptd. 1 B100062 B100062
2 Bottom Casting Ptd. 1 B100063 B100063
3 Hinge Pin 2 B057804 B057804
4 Bridge Pin 2 B057805 B057805
6 10-24 Keps Nut 2 B073967 B073967
7 Standoff Lid Handle 2 B059271 B059271
8 10-24 x 3 1/2 Carriage 2 B059273 B059273
9 Lid Handle 1 B060312 B060312
10 1/4 x 5/8 Lock Washer 7 B100139
10 1/4 x 5/8 Lock Washer 2 B100139
11 1/4 - 20 Hex Nut 7 B100120
11 1/4 - 20 Hex Nut 2 B100120
12 1/4 - 20 x 1-1/2 Hex Bolt 2 B100112 N/A
13 Wood Side Shelf 1 B060324 N/A
14 Pull Handle Bracket 1 B053783 N/A
15 10 - 24 x 1 Screw 1 B100138 B100138
16 10 - 24 Wing Nut 1 B100125 B100125
17 Grease Tray Bracket 1 B060336 B060336
18 Grease Tray 2 B060337 B060337
19 1/4 - 20 x 1-1/4 4 B100114
19 1/4 - 20 x 1-1/4 2 B100114
20 #10 - 24 Speed Nut 1 B100121 B100121
21 9/32 ID X 5/8 Washer 5 B100136
21 9/32 ID X 5/8 Washer 3 B100136
22 45° Copreci Valve 1 B069751 B069750
23 Hose & Regulator 1 B069756 N/A
24 Control Panel Assembly w/Label 1 B100188 B100188
- Control Panel Label (Not Shown) B058123 B058123
25 Ignitor (Pushbutton) 1 B885160 N/A
26 Valve Knob 2 B070084 B070084
27 10 - 24 x 3/8 Screw 2 B100137 B100137
28 Burner Assembly 1 B053791 B053791
29 Collector Box Assembly 1 B056482 N/A
30 Warming Rack 1 B878363 B878363
31 Briquet Rack 1 B070404 B070404
32 Ceramic Briquets 1 B058122 B058122
33 Cooking Grids 1 B878361 B878361
34 #8 x 1/2 Screw 1 B100140 N/A
35 Handle Spacer 1 B662325 N/A
REPAIR PARTS AND WARRANTY
Periodic inspections and maintenance are essential. All Gas Grill products eventually begin to wear due to environment,
contaminants, erosion or aging or components made of metal or rubber. Inspect all components at least two times per
year and replace when necessary.
A repair parts pamphlet is provided with this manual. When placing a repair part order with your Broilmaster dealer, refer
to the pamphlet for repair part information.
A warranty is provided with this manual. For warranty claims, follow the instructions provided by the warranty.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
