ECOXGEAR C2CDRW: Retrowriter - Manual (Page 8)

Listening to the Radio
1. Select AM or FM using the AM/FM button.
2. Tune to the desired frequency.
3. Rotate the VOLUME knob clockwise or counterclockwise
to
adjust the desired sound level.
Listening to a Record
1. Press the PHONO button once to select PHONO.
2. Gently open the dust cover.
Be
not to pinch your finger.
3. Put the record on the turntable.
When playing a 45 RPM record,use the included adapter.
4. Select the speed.
careful
14 15
AM/FM TUNING VOLUME
CD RECORDER
FINALIZE REC
0 1 2 3 4 5 6 7 8 9 10 7 88 90 92 94 9 6 9 8 100 104 1 06 1 108 0 0 0 0 530 600 700 900 1000 0 14 171 12 0 FM AM MHz KHz PHO NO
CD AM/ FM
AUX
ERA SE
REMOTE SENSOR
1
2 3
PHONO
TUNING
VOLUME
TUNING VOLUME
CD RECORDER
FINALIZE REC
0 1 2 3 4 5 6 7 8 9 10 7 88 90 92 94 9 6 9 8 100 104 1 06 1 108 0
0 0 0 530 600 700 900 1000 0 14 171 12 0 FM AM MHz KHz PHO NO
CD AM/ FM
AUX
ERA SE
REMOTE SENSOR
1
33
45
78
5 5
4 4
Adapter
