Dreams Manhattan Bedstead - Manual (Page 3)

3
1 A B C
10mm
1
3
2
3
Bed Assembly
Stage
1
Fit the bolts (A), spring washers (B), and
flat washers (C) to the holes in the headboard (1) and footboard
(2) as shown. Note: Do not fully locate the bolts, but leave 10mm protruding.
Fit the side rails (3) to the headboard and footboards locating the
fixing brackets behind the flat washers.
Once all four corners are located check the bed is square, then fully tighten the bolts using the allen key (D).
Stage
2
A x8 B x8 C x8
M C x8 x8
ARROWS ON LABELS
POINT TO EACH OTHER
C
M
11A
Fi
t pairs of adjustable support legs to side rails (11A &11B) - fix them into pre-threaded holes with bolt/washer (M&C).
Page 3 of 6
3
3
11A
11A
11B
11B
