Dreams Angel Bedstead - Manual (Page 3)

2
1
Bed Assembly
Stage
1
A x8 B x12 C x12A
(N.B. at the last step, you must tighten these bolts very tightly). Fit the bolts (A), spring washers (B) , and flat washers.
(C) to the holes in the footboard (2) as shown. N.B. Do not fully locate the bolts, but leave 10mm protruding then,
fit the side rails (4 & 5) to the footboard locating the brackets behind the flat washers.
Stage
2
Fix legs (3) in the marked positions, on underside of headboard (1) and footboard (2)
.
Page 3 of 4
1
5
4
2
3
1 2
&
1
4
5
Fit the bolts (I), spring washers (B) , and flat washers (C) through side rails (4 & 5) to the holes in the headboard (1)
I x4
4
1
I
C
B
2
5
A B C
10mm
2
A B C
5
2
Once all four corners are located, make sure the bed is square, then tighten the bolts using allen key (D).
