23
PUSH STICK
MAKE
FROM 1/2" OR
3/4"
WOOD
OR
THICKNESS
LESS
THAN
WIDTH
OF
MA
TERIAL TO
BE
CUT
CUT
OFF
HERE
TO
PUSH 1/4" WOOD
CUT
OFF
HERE
TO
PUSH 1/2" WOOD
NOTCH
TO
HELP
PREVENT
HAND
FROM
SLIPPING
1/2" SQUARES
CONSTRUCTING A PUSH STICK
When ripping work less than 4 inches wide, a push stick should be used to complete the feed and could be easily made
from scrap material by following the pattern shown in Fig. 53.
Fig. 53
