CF1400/CF2300 Burner Manual

The fuel unit nozzle port pressure is factory set at 300
psig. Some original equipment manufacturer burner
applications may call for a lower pressure to obtain a
required fi ring rate. Do not change this pressure unless
directed to do so by the appliance manufacturer.

Electrical Supply

Verify that the power connections available are correct
for the burner. Refer to Figure 1. All power must be
supplied through fused disconnect switches.

Figure 1 – Typical Nameplate

Vent System

The fl ue gas venting system must be in good condition
and must comply with all applicable codes.

Verify Burner Components

Burner nameplate (Figure 1), Model CF1400 or
CF2300A
Air tube assembly
Mounting fl ange kit
Pedestal mounting assembly kit (recommended)
Oil nozzle, per Table 1 — Use only 45° to 70°
solid pattern nozzles unless otherwise shown by
appliance manufacturer or on the burner nameplate
rating label.

Find the required fi ring rate in the 300 psig column (high
fi re rate). Select the corresponding nozzle from column 1
(Rated gph @ 100 psig).

(Example: a 5.00 gph nozzle @ 300 psi = 8.66 gph)

Verify Firing Rate

Refer to appliance manufacturer’s instructions (if
available) for fi ring rate and nozzle selection. Otherwise,
the maximum recommended fi ring rate for the burner
depends on the length of the fi ring chamber and the
distance from the burner center to the chamber fl oor.
Verify that the chamber dimensions are at least as
large as the minimum values given in Figure 2. If the
appliance dimensions are smaller than recommended,
reduce the fi ring rate accordingly.




Table 1 – Nozzle Capacities

Rated

gph

@100

psig

Pressure - Pounds per square inch

125

140

150

175

200

250

275

300

3.00

3.35

3.55

3.67

3.97

4.24

4.74

4.97

5.20

3.50

3.91

4.14

4.29

4.63

4.95

5.53

5.80

6.06

4.00

4.47

4.73

4.90

5.29

5.66

6.32

6.63

6.93

4.50

5.04

5.32

5.51

5.95

6.36

7.11

7.46

7.79

5.00

5.59

5.92

6.12

6.61

7.07

7.91

8.29

8.66

5.50

6.15

6.51

6.74

7.27

7.78

8.70

9.12

9.53

6.00

6.71

7.10

7.35

7.94

8.49

9.49

9.95

10.39

6.50

7.26

7.69

7.96

8.60

9.19

10.28

10.78

11.26

7.00

7.82

8.28

8.57

9.25

9.90

11.07

11.61

12.12

7.50

8.38

8.87

9.19

9.91

10.61

11.86

12.44

12.99

8.00

8.94

9.47

9.80

10.58

11.31

12.65

13.27

13.86

8.50

9.50

10.06

10.41

11.27

12.02

13.44

14.10

14.72

9.00

10.06

10.65

11.02

11.91

12.73

14.23

14.93

15.59

9.50

10.60

11.24

11.64

12.60

13.44

15.02

15.75

16.45

10.00

11.18

11.83

12.25

13.23

14.14

15.81

16.58

17.32

10.50

11.74

12.42

12.86

13.89

14.85

16.60

17.41

18.19

11.00

12.30

13.02

13.47

14.55

15.56

17.39

18.24

19.05

12.00

13.42

14.20

14.70

15.88

16.97

18.97

19.90

20.79
