Condux Fiber Optic Jamb Skid User Manual

Page 3

background image

!CAUTION: Do not lower the Jamb

Skid sections into the manhole by

hand. Personal injury or property

damage may result.

!WARNING: Do not use around live

circuits. The aluminum Jamb Skid is

highly conductive. Serious personal

injury or death may result.

!WARNING: Ensure the Jamb Skid is

properly aligned with the duct and the

cam-lock foot pedal is fully locked.

Do not exceed 10,000 lbs. of pulling

force. Failure to do so may result in

personal injury or property damage.

!CAUTION: The Jamb Skid locking

pins rotate freely. Do not use the

Jamb Skid as a ladder. Personal

injury may result.

Figure 2

75°

Manhole

Sheave

Duct

Jamb Skid

Cable

Figure 1

Locked

Fully Engaged

Disengaged

Figure 3

Sheave

Duct

Jamb Skid
