2.13 Engine
Cover:
Engine
Shall
Be
Covered
for
Noise
Reduction
Allowing
for
Easier,
Safer
Communication
Near
the
Machine.
2.14 Swivels:
Unit
Shall
Include
One
(1)
2500#
Standard
Pulling
Swivel
&
One
(1)
7000#
Standard
Pulling
Swivel
3.0
TRAILER
SPECIFICATIONS
3.1
Dimensions:
96”
Height
/
80”
Width
/
144”
Length
3.2
Weight:
Approximately
4500
lbs
w/Pulling
Rope
3.3
Trailer
&
Frame:
All
High
Strength
Steel
Channel
&
Tubing
/
Welded
Solid
Construction
3.4
Axle:
Single
Axle
Rated
@
6000
lbs
3.5
Tires:
LT
215/75-­‐R17.5-­‐H
3.6
Hitch:
Adjustable
Height
3”
Pintle
Eye
w/Safety
Chains
3.7
Grounding:
5/8”
Copper
Grounding
Loop
3.8
Brakes:
Electric
w/Break-­‐a-­‐Way
Switch
3.9
Electrical
System:
12V
DC
w/DOT
Approved
Lighting
3.10
Tool
Box:
All
Aluminum
–
Trailer
Mounted,
Locking
3.11
Stabilizing
Jacks:
Hydraulic
Front
&
Rear
4.0
OPTIONAL
ACCESSORIES
4.1 Winchline
Blower
Kit:
For
Blowing
Winch
Cable
Into
Conduit.
Available
for
2”,
2
½”,
3”,
4”,
5”,
6”
&
8”
Conduit
(Kit
Includes
Remote
Head,
Control
Lever,
Air
Gauge,
Hose
and
Carriers
(Birdies).
4.2 Conduit
Feeding
Sheaves:
For
Rigging
and
Cable
Protection
of
the
Feed
End
of
Pull.
Available
for
2”,
2
½”,
3”,
4”,
5”,
6”
&
8”
Conduit
4.3 A
Frame:
Attachment
Shall
Secure
to
Hydraulic
Arm
and
Allow
for
Pulling
of
Additional
Cable
(Slack)
