1.
Ensure the swivel is the correct size for the job (see Tables 1 & 2),
and test the swivel for proper operation.
2. Unscrew
the
clevis pins with a straight-slot screwdriver (
7
⁄
8
"
swivels) or an Allen wrench (
5
⁄
8
" swivels).
3.
Attach the swivel between the cable’s pulling eye or grip and the
pulling rope.
4.
Tighten the clevis pins securely.
NOTE: Swivels are not designed to run around bullwheels.
1.
Removal is the opposite of the installation procedure.
NOTE: Replacement pins are available from Condux.
Installation Procedure
!WARNING: Read and understand all procedure
and safety instructions before using any Condux
®
Break-Away Swivel. Failure to do so may result in
personal injury or property damage. Save this
user’s guide for future reference.
!WARNING: The Break-Away Swivels are for cable
installation only. Do not use them for any other
purpose or severe personal injury and property
damage could result.
!CAUTION: Wear personal protective equipment:
hard hat, safety glasses, safety shoes, and leather
work gloves. Failure to do this could result in
personal injury
!WARNING: Do not stand directly behind the pull
string. If any component breaks, severe personal
injury or property damage could result.
Removal Procedure
!ADVERTENCIA: Favor de leer y comprender todas
las instrucciones de operación y seguridad antes
de usar el Condux
®
Break-Away Swivel. Si Ud. no
comprende las instrucciones favor de consultarle
a su jefe.
ADVERTENCIA
Instrucciones
de Operación
5
⁄
8
" Swivel (16 mm)
Part
Break Load
Number
(lbs)
(N)
08017300
200
890
08017400
250
1,112
08017800
300
1,334
08016900
450
2,002
08017200
600
2,669
08017500
650
2,891
08017900
750
3,336
7
⁄
8
" Swivel (22 mm)
Part
Break Load
Part
Break Load
Number
(lbs)
(N)
Number
(lbs)
(N)
08018100
150
667
08018700
800
3,558
08018300
200
890
08018800
850
3,781
08018000
250
1,112
08076600
900
4,003
08017600
300
1,334
08015700
1,000
4,448
08018400
350
1,557
08018900
1,100
4,893
08075300
400
1,779
08015200
1,200
5,338
08015800
450
2,002
08019100
1,300
5,782
08076500
500
2,224
08074600
1,400
6,227
08018500
550
2,446
08076900
1,500
6,672
08015000
600
2,669
08019200
1,600
7,117
08018600
650
2,891
08019300
1,700
7,562
08076000
700
3,114
08017700
1,800
8,006
08075500
750
3,336
Table 1.
5
⁄
8
" Break-Away Swivels
Table 2.
7
⁄
8
" Break-Away Swivels
®
CONDUX
Figure 1. Break-Away Swivel
Clevis Pins (2)
