Behringer PRO MIXER DJX750 - Manual (Page 9)

9 PRO MIXER DJX750 User Manual
Specifications 6.
Audio Inputs
Mic 40 dB Gain, XLR,
electronically balanced input stage
Phono in 40 dB Gain, unbalanced input
Line in 0 dB Gain, unbalanced inputs
CD in 0 dB Gain, unbalanced inputs
Return 0 dB Gain, unbalanced input
Audio Outputs
Master max. +21 dBu
Booth max. +21 dBu
Tape typ. 0 dBu
Send typ. 0 dBu
Phones Out max. 180 mW @ 75 W / 1% THD
Equalizer
Stereo Low +12 dB/-32 dB @ 50 Hz
Stereo Mid +12 dB/-32 dB @ 1.2 kHz
Stereo High +12 dB/-32 dB @ 10 kHz
Mic Low +15 dB/-15 dB @ 80 Hz
Mic Mid +15 dB/-15 dB @ 2.5 kHz
Mic High +15 dB/-15 dB @ 12 kHz
Kill Low -54 dB @ 50 Hz
Kill Mid -44 dB @ 1 kHz
Kill High -26 dB @ 10 kHz
Digital Effects Processor
DSP Freescale
A/D-D/A converter 24-bit Sigma-Delta,
64/128-times oversampling
Sampling rate 46.875 kHz
System specifications
Signal-to-noise ratio > 80 dB (Line)
Crosstalk > 70 dB (Line)
Distortion (THD) < 0.03%
Frequency response 10 Hz - 55 kHz, +0/-3 dB
Power supply
Power consumption 32 W
Mains connection Standard IEC receptacle
Mains voltages/Fuses
100 - 120 V~, 50/60 Hz T 1 A H
220 - 230 V~, 50/60 Hz T 500 mA H
Dimensions/Weight
Dimensions (H x W x D) approx. 4 1⁄10 x 12 1⁄20 x 14 3⁄5"
approx. 104.3 x 320 x 370.8 mm
Weight approx. 8 1⁄2 lbs / approx. 3.9 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
