Motronic manifold injection
Further technical information can be found
in the “Motronic” booklet.
Part number 1 987 722 161.
The booklets are available from franchized
Bosch wholesalers. The Motronic combines the injection and
ignition systems to form an engine-manage-
ment system. Fuel metering and ignition are
optimally matched. Other electronic func-
tions can also be incorporated. Digital data
processing and the use of microprocessors
make it possible to convert a wide range of
operating data into map-controlled injection
and ignition data. Electric fuel pump
Fuel filter
Fuel-pressure regulator
Injector
Air-flow sensor
Engine-temperature sensor
Rotary idle actuator
Throttle-valve switch
Engine-speed/reference-mark sensor
N Lambda Sensor
O Electronic control unit
Q High-voltage distributor
