CLEARANCES FOR MODEL 74
MINIMUM CLEARANCES TO COMBUSTIBLES
RESIDENTIAL / MOBILE HOME
DOUBLE WALL OR SHIELDED SINGLE WALL
CONNECTOR WITHOUT CLOSE
CLEARANCE SHIELDS
Figure 10
MODEL
A
B
C
D
E
F
G H
MODEL 74
25"
4"
6.5" 4"
8"
6"
20" 10”
NOTE: All clearances are to combustibles with all low clearance shields and double wall
pipe and minimum floor protector.
C
C
D
D
BACK WALL
SIDE WAL
L
A
E
B
F
D
G
C
G
B
C
H
F
A
E
