Brinkmann 2600 Series User Manual
Page 29
28
Step 19
Place the porcelain coated heat
shields on lower level of grill body
assembly directly above burners.
Step 20
Place porcelain cast iron cooking
grills on support ribs directly
above porcelain heat shields.
Step 21
Place warming rack in slots above
cast iron cooking grills.
Warming Rack
Cooking Grills
Porcelain Heat
Shields
Pro Series 2600 (Assembled)
