Appendix - 73 -
English
After the completion, you will see the detailed information about the RAID, such as RAID level, disk
block size, disk name and disk capacity, etc.
Intel(R) Matrix Storage Manager option ROM V5.0.0.1011 ICH7R wRAID5
Copyright(C) 2003-04 Intel Corporation. All Rights Reversed.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes :
ID
Name Level Strip Size Status
Bootable
0
RAID_Volume0 RAID(Stripe) 128KB 223.5GB Normal Yes
Physical Disks :
Port
Driver Model Serial # Size Type/Status(Vol ID)
0 ST3120026AS 3JT329JX 111.7GB Member Disk(0)
1 ST3120026AS 3JT354CP 111.7GB Member Disk(0)
[ ]-Select [ESC]-Exit [ENTER]-Select Menu
Delete RAID Volume
If you want to delete a RAID volume, please select the Delete RAID Volume option. Press Enter key
and follow the instructions on the screen.
Intel(R) Matrix Storage Manager option ROM V5.0.0.1011 ICH7R wRAID5
Copyright(C) 2003-04 Intel Corporation. All Rights Reversed.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes :
ID
Name Level Strip Size Status
Bootable
0
RAID_Volume0 RAID(Stripe) 128KB 223.5GB Normal Yes
Physical Disks :
Port
Driver Model Serial # Size Type/Status(Vol ID)
0 ST3120026AS 3JT329JX 111.7GB Member Disk(0)
1 ST3120026AS 3JT354CP 111.7GB Member Disk(0)
[ ]-Select [ESC]-Exit [ENTER]-Select Menu
