2-3 Integrated Peripherals
On-Chip Primary PCI IDE
Enabled Enable onboard 1st channel IDE port. (Default value)
Disabled Disable onboard 1st channel IDE port.
On-Chip Secondary PCI IDE
Enabled Enable onboard 2nd channel IDE port. (Default value)
Disabled Disable onboard 2nd channel IDE port.
SATA RAID / AHCI Mode
RAID Set the onboard SATA controller to RAID mode. (Default value)
AHCI Set the onboard SATA controller to AHCI mode. Advanced Host Controller Inter-
face (AHCI) is an interface specification that allows the storage driver to enable
advanced Serial ATA features such as Native Command Queuing and hot plug.
For more details about AHCI, please visit Intel's website.
Disabled Set the onboard SATA controller to IDE mode.
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Integrated Peripherals
On-Chip Primary PCI IDE [Enabled]
On-Chip Secondary PCI IDE [Enabled]
SATA RAID/AHCI Mode [RAID]
x On-Chip SATA Mode Auto
x PATA IDE Set to Ch.1 Master/Slave
SATA Port 0/2 Set to Ch.2 Master/Slave
SATA Port 1/3 Set to Ch.3 Master/Slave
USB Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
Azalia Codec [Auto]
Onboard H/W 1394 [Enabled]
Onboard H/W SATA1 [Enabled]
H/W SATA Function1 [RAID]
Onboard H/W GigaRAID [Enabled]
GigaRAID Function [RAID]
Onboard H/W LAN1 [Enabled]
Onboard H/W LAN21 [Enabled]
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F3: Language F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
If a hard disk
controller card is
used, set at Disabled.
[Enabled]
Enable on-chip IDE
Port.
[Disabled]
Disable on-chip IDE
Port.
Only for GA-8I955X Royal.
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Integrated Peripherals
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F3: Language F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level` Onboard LAN1 Boot ROM [Disabled]
Onboard LAN2 Boot ROM1 [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
i-Lock [Enabled]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
