IPAEL-GS motherboard layout reference
Specifications summary
CPU Socket: Intel Socket 775
Supports: Conroe, Kentsfield, Wolfdale, Yorkfield, Conroe-L
Front Side Bus: 800/1066/1333 MHz
Chipset MCH (North Bridge): Intel P45
ICH (South Bridge): Intel ICH10R
Memory Dual channel, 4 slots, Non-ECC, Unbuffered, 240 pin DDR2, max 16GB
Types: 667/PC2-5400, 800/PC2-6400
Expansion slots 2x PCI Express Graphic slot (x16)
2x PCI Express slot (x1)
3x PCI slot
Audio Azalia IDT 92HD73E CODEC (8 Channels)
LAN Intel 82567V Gigabit Ethernet PHY
Graphic None
Storage/RAID x SATA ports[H6$7$SRUW
1394 (optional) 1394a, 100/200/400Mbps, 2 ports (1 onboard, 1 on rear panel)
USB 12x USB 2.0 ports (6 onboard ports, 6 on rear panel)
Rear panel I/O ports 1x 1394 port (optional) + 2x USB 2.0 ports
2x USB 2.0 ports + 1x eSATA port
1x LAN port + 2x USB 2.0 ports
5x Audio out ports
1x
63',)DXGLRRXWSRUW
Internal connectors 1x SPDIF output header
1x Front panel audio header
1x 1394a front panel header (optioanl)
3x USB 2.0 dual port headers
1x Front Panel connector
1x 7-pin SATA header
2x 1 4-pin SATA headers
1x Serial (COM) port header (optioanl)
1x System chassis intrusion header (optional)
Power connectors 1x 24-pin EATX (+12V EPS power connector)
1x 4-pin ATX (+12V power connector)
1x 4-pin PCIe power connector
1x CPU FAN connector
3x System FAN connectors (Front/Rear/Aux) (default rear only)
Selectors Clear RTC
BIOS SPI Mb (AMI)
Form factor ATX form factor 1 in. x 9.6 in.
