IPMIP-GS motherboard layout reference
Motherboard layout
*HDMI port
(Depending on Model)
eSATA & USB
connectors
LAN & USB
connectors
Audio
ports
CD in
connector
Keyboard &
mouse
(PS/2) ports
ROM recovery
connector
SATA
connectors
Front panel
audio
connector
USB 2.0
connectors
FLASH override
selecter
USB 2.0
connectors
Memory
sockets
Front panel
connector
ATX power
connector
PCIE1
slot
PCIE4
slot
PCIE16 slot
Buzzer header
Internal serial
port connector
Chassis Intrusion
Alarm Connector
Clear CMOS
& password
selectors
Internal SPDIF
output connector
Internal SPDIF
output connector SPDIF_OUT1
INTRUDE
R
CD
ATX CPU Power
Connector
TPM
Connector
ATX_CPU
LAN + USB
AUDIO
CPU FAN
F_AUDIO
CMOS
+PW
ROM_RECOVERY
F_PANEL
F_USB5 F_USB4
FLASH_OVERRIDE
F_USB2 F_USB1 F_USB3
PCIE X16 SLOT
PCIE X4 SLOT
XIMM2 XIMM1 XIMM4 XIMM3
PCIE X1 SLOT1
PCI SLOT
BATTERY
BUZZER
System Fan
Connector
Keyboard
Power selecter
CPU Fan
Connector
SYSTEM FAN
SW51
KB PWR
HDMI
eSATA + USB
TPM
SATA0
SATA
SATA4 SATA2
SATA3 SATA1
SERIAL_A
AT
XPOWE
R
KB +MS
Clear ME
data selector
Intel
LGA1156
socket
SPDIF_OUT2
PCI
slot
Display
ports
(DVI)(VGA)
DVI+VGA
BUZZER_HEADER
