2
IPMIP-GS motherboard layout reference
Specifications summary
CPU Socket : Intel Socket 1156
Supports : Clarkdale
Chipset North Bridge : Ibex peak (H55/H57/Q57)
Memory Dual-channel, 4 slots, Non-ECC, Unbuffered, 240 pin DDR3, Max. 16GB
Types: 1066/PC3-8500, 1333/PC3-10600
Expansion slots 1x PCI Express slot (x16)
1x PCI Express slot (x4)
1x PCI Express slot (x1)
1x PCI slot
Audio ALC888S-VC2 (8-channel) or ALC662 (6-channel)
LAN Gigabit: Intel hanksville (PHY)
USB 14x USB 2.0 ports, 12/480Mbps (12 ports on H55 sku)
Rear panel I/O ports 1x Mouse (PS/2) port + 1x Keyboard (PS/2) port
1x Display (VGA) port + 1x Display (DVI-I) port
* Display (HDMI) port
1x LAN (RJ-45) port + 2x USB 2.0 ports
2x USB 2.0 ports + 1x e-SATA port
6x Audio jacks ( * Audio Channel)
Internal connectors 1x ATX CPU power connector
1x ATX power connector
1x CPU fan connector
1x System fan connector
5x SATA connectors
1x Front panel audio connector
2x Internal SPDIF output connectors
1x CD in connector
1x Internal serial port connector
5x USB 2.0 connectors
1x TPM connector
1x Chassis intrusion alarm connector
1x Front panel connector
BIOS SPI 64Mb for H/Q SKU (AMI)
Form factor microATX, 9.6 inches x 9.6 inches
* The following components may be available depending on model.
Model HDMI port Audio Channel
Super model Optional 8-channel or 6-channel
H55 No HDMI port 5.1 channel
H57/Q57 No HDMI port 8-channel or 6-channel
