System Map: Front View with LCD Panel Open
(Model B)
Figure 4
Front View with LCD
Panel Open (Model B)
1.
Built-In PC Camera
(Optional)
2.
LCD
3.
Power Button
4.
Hot-Key Buttons
5.
LED Status Indicators
6.
Keyboard
7.
Touchpad & Buttons
8.
LED Power &
Communication
Indicators
9.
Fingerprint Module
(Optional)
10. Built-In Microphone
Note the cleaning in-
structions for alumi-
num covers - see
2
1
7
8
4
5
9
3
6
10
TouchPad buttons
(valid operation area)
7
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmission
devices aboard aircraft is usually prohibited.
Make sure the wireless modules are OFF if
you are using the computer aboard aircraft.
Use the appropriate function key combination
(see
) to toggle power to the
wireless modules (3.5G/WLAN/Bluetooth), and
check the LED indicator
/
to see if the
modules are powered on or not (see
Table 2, on
page 12
).
