11
Part Name and Functions (Rear) – Compact Type
No. Part Functions
①
DC 12V DC 12V Power Input Only
②
Recovery Recovery Button
③
LAN NETWORK (LAN) connector port.
④
USB Port USB connector port
⑤
VGA VGA Video Signal Output Port
⑥
CH’s SD Composite Video Signal Input Port (BNC type connector)
⑦
HD-SDI HD-SDI Video Signal Input Port
