Cambridge SoundWorks Soundworks Radio 735 User Manual
Page 19
- 1 -
PLAYER
POWER
OUTPUT
INPUT
AM
ANTENNA
FM ANTENNA
EXT
INT
INPUT
75 OHMS
PLAYER
INPUT
POWER OUTPUT FOR OPTIONAL PLAYER DOCK
AM ANTENNA INPUT MINIJACK
.mm STEREO MINIJACK PLAYER INPUT
FOR OPTIONAL PLAYER DOCK
QUICK REFERENCE GUIDE - SOUNDWORKS RADIO REAR CONNECTIONS
INTERNAL / EXTERNAL FM
ANTENNA SELECTOR
EXTERNAL FM ANTENNA “F”
TYPE INPUT
