7

1. Decide where you want the MC300IW speakers to

be placed. Using a stud-finder (or other means),

locate the nearest wall stud adjacent to this loca-

tion. Adjust your loudspeaker placement so that the

necessary wall cutout will not intersect the stud.

The resulting wall cutout should be at least 1/2"

away from any stud. When you are using the

MC300IW horizontally as a center channel there is

very little room for error.

2. Use the supplied template to scribe the area to be

cut out. It is recommended that a level or other

device be used to square the template to other

reference points within the room. While there is

some degree of freedom to adjust the speaker in

the hole, it is best to have a level mounting hole to

begin with.

3. Remove the cutout area using your preferred tool.

If you are cutting into a wall or ceiling with a plaster

skim-coat, drill a small hole at each corner first to

reduce the chance of a spreading crack.

Note:

When cutting into a wall or ceiling, be careful

not to cut into items such as wiring, conduit, or

plumbing. It is often difficult to know exactly what

lies behind a cutout area. If you are not certain, first

make a smaller (3/4" – 1") inspection hole in the

center of the cutout using a drill. Using a flashlight

and a probe, inspect the area behind the wall

before making your final cut.

4. If your cut is on an outside wall, the wall will most

likely contain some form of insulation. Fiberglass

batting type insulation should be left in place, as it

is sonically desirable and will hold its own shape.

Blown-in cellulose or loose glass fibers must be

removed from the area behind the speaker, as they

will get agitated by the speakers’ vibration. If your

wall contains this type of loose insulation, remove it

from the area immediately behind the speaker and

replace it with a pad of fiberglass batting which is

at least 50% larger than the cutout in each direc-

tion. Also, if you are locating the speaker on an

inside wall, installing fiberglass batting in the space

between the studs is recommended, as it will

provide an improvement in sound quality.

INSTALLATION
