USE AND PLACEMENT CONSIDERATIONS

5

The MC300IW is designed as an LCR loudspeaker.

This means that it is both ideal as a main Left and

Right channel loudspeaker, and equally suitable as a

horizontal center channel loudspeaker in a home the-

ater system. The compact MTM (Mid-Tweeter-Mid)

array, and crossover topology used in the MC300IW

allow it to be used both vertically and horizontally with

even dispersion. The MC300IW uses shielded magnet

assemblies, so that it may safely be built in to a cabi-

net or wall adjacent to a CRT based video monitor.

Because the MC300IW has very wide and uniform dis-

persion there is a great deal of flexibility in placement.

The ideal location should provide an unobstructed

path from the speakers to the listeners.

For the best effect used as a stereo pair for music

separate the speakers by at least four to eight feet.

The ideal separation is roughly equal to the distance of

the speakers to the listener. Try to place the left and

right speakers at a similar distance from the primary

listening position.

Similar rules apply when used as part of a home

theater installation. For the best home theater effect,

the speakers should be placed symmetrically around

the video monitor. The Center channel should be

placed as close to the monitor as possible, centered

directly above or below it.

To reduce the detrimental effects of side wall reflec-

tions on imaging, it is best to keep the speakers at

least 18" away from room corners or wall/ceiling borders.

The MC300IW has adequate bass range to be used

as a full range speaker in small rooms at moderate

levels. In home theater applications, or in larger

rooms, use of a subwoofer is strongly recommended.

See your Cambridge SoundWorks retailer or installation

professional for help in selecting a suitable subwoofer.
