Surface mounting
Front panel mounting
Rear panel mounting
PANEL
0.125"
3.18mm
BULKHEAD
0.750"
19.05mm
1.900"
48.26mm
1.930"
49.02mm
Common
Battery
Starter
or other load
m
-Series Battery Switch Dimensions
2.175"
56.24mm
2 5/8"
(67mm)
2 5/16" (59mm)
2.175"
56.24mm
#10 (M5)
screw
Cutout
Dimension
Switch Mounting Options
