SM427 | Bicycle Handlebar Mount with Universal Holder
Package Contents:
(1) SM050-2 - Slim-Grip™ Universal phone and smartphone holder
(1) GN014-SBH - Mini Windshield Suction and Dashboard Mount
GN014-SBH
Mini Windshield
Suction Pedestal
SM514-KR |
Slim-Grip™ Universal Phone and Smartphone Holder with Mini Windshield Suction and Dashboard Mount
82 mm
expandable to
118.5 mm
Connect the dual T-slots (A) on holder to the dual T-tabs (B) on
the pedestal head.
A
A
A
A
B
B
B
A
Optional Cord
Catcher
Secure holder with your hand for support, as spring-loaded
mechanism requires signifi cant force to operate. Hold your phone
and insert into universal holder by pushing down on the bottom
spring-loaded support legs with moderate amount of pressure
(C). Slide the top of the device under the top support legs (D) until
it fi ts snuggly in the holder.
Insert Phone into Holder
D
C
Connecting the Slim-Grip™ Holder to Dual T-Tab Pedestal Windshield Mounting
Install the Support Legs to the Holder
Step 1.
Step 1.
Step 1.
Step 1.
Find a safe location on the interior of the vehicle’s windshield
to mount the pedestal. Firmly push the suction base (A)
against the windshield and fl ip the base lever down (B) to the
locked position. See diagram below.
Insert the holder support legs (A) by sliding them into the
support leg grooves (B) on the top and bottom of the holder.
A
B
Continued on other side...
!
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
SM050-2
Slim-Grip™
Universal Phone Holder
al
expanda
118.
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Designed in USA | Made in China And Taiwan
© Copyright 2010 Arkon Resources, Inc.
www.arkon.com
Arcadia, CA 91006 USA
Representative in KOREA
www.knctek.com
TEL : 02) 839-5701
FAX : 02) 830-5703
࣬৹ࢄߔ޺੦
Most smartphones, mobile phones, and •
cell phones having heights between
80mm and 115mm tall
Apple iPhone - All models
•
RIM BlackBerry - All non-fl ip models •
HTC Phones - All non-fl ip models •
Motorola Phones - All non-fl ip models •
Nokia Mobile Phones - All non-fl ip models •
Palm - All non-fl ip models •
LG Mobile Phones - All non-fl ip models •
Samsung - All non-fl ip models •
Sony Ericsson - All non-fl ip models •
Sanyo - All non-fl ip models •
Pantech - All non-fl ip models •
Google - All non-fl ip models •
All brand names and product names are trademarks or registered trademarks of their respective owners.
Holder included is Universal, designed to fi t nearly ALL non-fl ip mobile
phones regardless of whether a protective case or silicone sleeve is attached
to the phone.
