Black & Decker BB212 User Manual

Bb212

Package Contents:
(1) SM012 - Mini friction dashboard mount
(1) GN014-SBH - Travelmount® Mini swivel head windshield mount
(1) CC001-BB - Custom Holder for BlackBerry Tour, Curve, Bold 9650 and 9700
(1) Optional adhesive safety hook (recommended but not required)
(1) Alcohol cleaning pad

Do not place mount in or near an air bag deployment zone
or where it will obstruct view of the road.

Dashboard Mount Installation

Find a safe location on the vehicle dashboard that is not in an
air bag deployment zone.

Optional Safety hook installation will add extra stability.
Clean the area with the included alcohol pad and let dry.
Remove the adhesive backing on the safety hook base. The
hook curve must point towards the windshield. Press and
hold the hook down on the dashboard surface for about
a minute. Allow 24 hrs. to cure to the dashboard at room
temperature (72° F).

Loop the back of the dashboard mount around the safety
hook and place on the dashboard in front of the hook. Remove
the protective fi lm from pedestal mounting surface (A).

Step 1.

Step 2.

Step 3.

WIN

DSH

IELD

Hook towards windshield

BB212 |

Mini Friction Dashboard Mount for BlackBerry® Tour™, Curve™, Bold 9650™ and 9700™

Patent Pending

Lower the mount onto the disc and press down fi rmly. Flip the
locking lever (D) down to secure the pedestal to the dash mount.

Install the BlackBerry holder by inserting the dual T-tabs
(E) on the mount into the T-slots (F) on on the back of the
holder.

Insert adhesive pads (G) at the holder base as shown so the
device can fi t securely. Place the bottom of the BlackBerry
device (device not included) on the pads and lift up on the
large tab (H) at the top of the holder. Gently push the top of
the device into the holder and lower the tab to secure.

Step 2.

Step 3.

Patent Pending

SM012
Mini Friction Dashboard
Mount with Travelmount™
Mini Swivel Head Pedestal

CC001-BB
Holder for
BlackBerry

Adhesive
Safety Hook

Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.

Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.

The Mobile Mounting Specialists™

Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST

www.arkon.com

Arcadia, CA 91006 USA

Designed in USA | Made in China and Taiwan

Compatible with:
• BlackBerry Tour, Curve, Bold 9650 and 9700 Smartphones

BlackBerry brand name and Tour, Curve, and Bold product names are trademarks or
registered trademarks of Research in Motion, Ltd.

Step 1.

Swivel Ball Head Assembly Attachment

Slip the tightening ring (A) over the pedestal ball. Snap
the dual-T head adapter plate (B) on to the pedestal ball
(C). Screw the tightening ring over the adapter plate until
securely holding the plate. Adjust the angle as needed.
