Instructions for installing safety features

2. Confirmation

-Check if all wires are connected securely. Insufficient wiring may

*Important

-the parking brake wire (purple) must have ground

cause poor actuation of the product. In the worst case, it may

signal at all times, either by grounding the wire or

result in the breakdown of the engine.

reading ground signal from the parking brake wire.

-Be sure wiring are neatly installed without any interference with

If purple wire is not install correctly, the turbo timer

surrounding parts. Short circuit may occur due poor connections.

will automatically shut off when key is taken out.

In the worst case, it may result in breakdown or the engine.

CAUTION: When confirming actuation of turbo timer, be sure that

1. Parking brake. Purple wire

the gear is in neutral or parking position and the foot

A. Single wire parking brake.

is on the brake. Also be sure there is no one around the

connect purple wire as

vehicle.

shown in figure A.

B. More than one wire.

In case of Failure of product

a. Turn key to ON position.

Check the following before concluding there is any failure of this

(do not start engine)

product.

b. Use test light to find the

1. Check if wires is connected securely and connectors is inserted

wire with 12V power

rigidly.

when the parking brake

2. Check if ground wire is ground correctly.

is down. Connect to

3. Check if tap is securely connected.

that wire as shown in

figure B.
CAUTION: Parking brake can be

bypass if purple wire

is grounded.

*Engine will shut off if the parking brake is release at anytime during count

down.
