Page 3

2. Confirmation

Instructions for installing safety features

-Check if all wires are connected securely. Insufficient wiring may

cause poor actuation of the product. In the worst case, it may

*Important

-the parking brake wire (purple) must have ground

result in the breakdown of the engine.

signal at all times, either by grounding the wire or

-Be sure wiring are neatly installed without any interference with

reading ground signal from the parking brake wire.

surrounding parts. Short circuit may occur due poor connections.

If purple wire is not install correctly, the turbo timer

In the worst case, it may result in breakdown or the engine.

will automatically shut off when key is taken out.

CAUTION: When confirming actuation of turbo timer, be sure that

the gear is in neutral or parking position and the foot

1. Parking brake. Purple wire

is on the brake. Also be sure there is no one around the

A. Single wire parking brake.

vehicle.

connect purple wire as

shown in figure A.

In case of Failure of product

B. More than one wire.

Check the following before concluding there is any failure of this

a. Turn key to ON position.

product.

(do not start engine)

1. Check if wires is connected securely and connectors is inserted

b. Use test light to find the

rigidly.

wire with 12V power

2. Check if ground wire is ground correctly.

when the parking brake

3. Check if tap is securely connected.

is down. Connect to

that wire as shown in

figure B.
CAUTION: Parking brake can be

bypass if purple wire

is grounded.

*Engine will shut off if the parking brake is release at anytime during count

down.
