Configuration using the PC 4-3
B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2
Groups
Each of the six groups can be set to provide different alarm reporting operations for
selected points.
Points
In the points section, any of the hardware inputs and outputs can be selected for the Cv2
to use as alarm reporting or remote control functions. There are 30 points available.
Directories
When an alarm is detected, the Cv2 will perform a specific sequence of events
determined by the entries in the directory. Six directories are available, providing
different actions for different groups.
Programming
The programming section is used to transfer the configuration database between the PC
and the Cv2. Recorded voices can also be transferred from the Cv2 and then back.
4.6 Program Functions - Basic mode
The menu and taskbar for the basic mode is shown below:
File Operations - same as shown for the Advanced mode.
Summary - same as shown for the Advanced mode.
Change Mode - same as shown for the Advanced mode.
Alarms
Alarm settings for the 8 inputs are configured here.
Controls
Control output settings are configured here.
General
Settings that concern the operation of the entire Cv2 are entered in the General section.
Programming Programming is the same as for the Advanced mode.
4.7 Configuring the Cv2 - Advanced mode
When configuring the Cv2, the sequence described in the following section is the simplest
