10
BD-125WP SAFETY
Polishing Pad Capacity
The BD-125WP uses a three (3), four (4), or five (5) inch (76, 102, or 127 mm) diameter, wet polishing
pad.
Tile Types
The BD-125WP can polish all variety of tile types including porcelain, terracotta, marble, quarry and
slate, or almost any other non-ferrous material.
Replaceable Motor Brushes
The BD-125WP is equipped with replaceable motor brushes to extend operating life.
Serial Number and Product Specification Label Location
The Serial Number and Product Specification Label is located on the right side of the BD-125WP as
shown.
PRODUCT SPECIFICATIONS
The BD-125WP Wet Stone Polisher is engineered as a handheld Wet Stone Polisher. The polisher
is designed with a 120V motor in a rugged plastic housing. BD-125WP Part# 167556, BD-125WP Kit
Part # 381504
Motor Specifications
Motor specifications for the BD-125WP are listed in the table below.
voltage 120V
Amperage 7.9
Frequency 50/60 Hz
RPM 3200 rpm
Weight 6 lbs.
