1620E 1828E
Item Part Number Description Quan
Figure “G” Main Power Control Box
""
1 B6562T
2 B6562U
3 B6564T
4 B6564U
5 S3262A
6 B6074U
7 S3263A
8 M1501A
9 P1175A
10 M1538A
11 P1064A
12 P1190A
13 M1307A
14 B6079K
15 P1170A
16 M1517A
17 M1525A
18 M1500A
19 M1235A
20 M1521A
21 M1524A
22 M1378A
23 U1061A
24 B6073U
25 M1529A
26 M1513A
27 N/A
28 N/A
29 N/A
30 N/A
31 P6486A
32 P6469A
33 P1172A
B6071T
B6071U
B6072T
B6072U
S3262A
B6074U
S3263A
M1501A
P1175A
M1538A
P1064A
P1190A
M1307A
B6079K
P1170A
M1517A
M1525A
M1500A
M1235A
M1521A
M1524A
M1378A
U1060A
B6073U
M1529A
M1513A
P1008A
P1007A
B6250K
B6251K
N/A
N/A
N/A
Main Control Box Assy (Complete w/items 5-15 & 22)
Main Control Box Only (Bare)
Hinged Door Assy (Complete w/items 16-21 & 23)
Hinged Door Only (Bare)
Gearmotor Coupling
Gearmotor Adjustment Plate
Gearmotor Adapter Plate
Gearmotor - Belt Conveyor Drive
Power Distribution Terminal Block (1620 Uses 1, 1828 Uses 2)
Gearmotor Power Supply
Fuseholder w/Cap
Fuse SC-5 Amp
Gearmotor Reversing Switch
Reversing Switch Mounting Bracket
Terminal Block
Solid State Relay
Thermal Pad
Temperature Control
Cooling Fan
Heat Sink
Fan Guard
Contactor
Rating Plate
Air Speed Control Mount Bracket Assy (VHVA Only)
Air Blower Speed Control (208V Only) (VHVA Only)
Air Blower Speed Control (240V Only) (VHVA Only)
Fuse SC-20 Amp (1828 Single-phase Only)
Fuseholder w/Cap (1828 Single-phase Only)
Junction Box (1828 Only)
Cover, Junction Box (1828 Only)
Power Cord Assembly, Single-phase (Not Shown)
Power Cord Assembly, Three-phase (Not Shown)
Strain Relief
1
1
1
1
1
1
1
1
1 or 2
1
2
2
1
1
1
3
3
2
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
Not Shown
